This similar triangles worksheet for Geometry covers similar triangle theorems (Common Core G-SRT.B.4, G-SRT.B.5), with a free PDF to print.

These 20 problems practice the Triangle Proportionality Theorem, similarity tests and geometric means (Common Core G-SRT.B.4, G-SRT.B.5). The first problems are quick one-step checks of the definitions and formulas from the lesson. The middle problems ask for diagrams, equations and careful reasoning in the style of a high school Geometry class. The last six problems are applications with mirrors, ladders, sails and land parcels.

Geometry · Common Core State Standards: G-SRT.B.4, G-SRT.B.5

Similar triangles worksheet: exercises 1 to 10

Exercise 1 – Side splitter

A line parallel to BC splits both sides in the same ratio.

DE is parallel to BC. AD = 4, DB = 6 and AE = 6. Find EC.

Exercise 2 – Find AD

In triangle ABC, DE is parallel to BC with D on AB and E on AC. \(AD = x\), \(DB = 10\), \(AE = 6\) and \(EC = 15\). Find x.

Exercise 3 – Find BC

In triangle ABC, DE is parallel to BC. AD = 8, AB = 20 and DE = 6. Find BC.

Exercise 4 – Parallel? yes

Is DE parallel to BC?

Is DE parallel to BC if AD = 5, DB = 7.5, AE = 4 and EC = 6? Explain.

Exercise 5 – Parallel? no

Is DE parallel to BC if AD = 6, DB = 9, AE = 5 and EC = 8? Explain.

Exercise 6 – Proportion with x

DE is parallel to BC. \(AD = x + 1\), \(DB = 6\), \(AE = x + 3\) and \(EC = 9\). Find x, AD and AE.

Exercise 7 – SAS similarity

SAS similarity: the included angles are equal and the sides are proportional (6/9 = 8/12).

Triangle ABC has legs 6 and 8. Triangle DEF has legs 9 and 12. Both have a right angle between the legs. Are they similar? Name the test and the scale factor.

Exercise 8 – SSS similarity

Triangle 1 has sides 4, 5, 6. Triangle 2 has sides 10, 12.5, 15. Triangle 3 has sides 8, 10, 13. Which triangles are similar to Triangle 1?

Exercise 9 – Altitude to the hypotenuse

Right triangle with legs 6 and 8.

Right triangle ABC has legs 6 and 8. Find the hypotenuse, the altitude h to the hypotenuse and the two segments AD and DB.

Exercise 10 – Geometric mean

Find the geometric mean of 4 and 9.

Exercises 11 and up

Exercise 11 – Altitude from segments

AD = 4 and DB = 9.

The altitude to the hypotenuse of a right triangle splits the hypotenuse into segments of length 4 and 9. Find the altitude.

Exercise 12 – Legs from segments

The hypotenuse of a right triangle is 25 and the altitude to it splits the hypotenuse into 9 and 16. Find both legs.

Exercise 13 – Pythagorean check

Use the legs 15 and 20 and hypotenuse 25 from the previous problem to verify \(a^{2} + b^{2} = c^{2}\) and connect it to \(pc + qc\).

Exercise 14 – Overlapping triangles

DE parallel to BC.

DE is parallel to BC, AD = 6, AB = 15 and BC = 20. Find DE.

Exercise 15 – Ratio of perimeters

Two similar triangles have corresponding sides 6 and 15. The smaller has perimeter 28. Find the perimeter of the larger and the ratio of their areas.

Exercise 16 – Three parallel lines

Three parallel lines cut two transversals. On one transversal the segments are 3 and 5. On the other the segments are x and 10. Find x.

Exercise 17 – Mirror problem

Reflection method: two similar right triangles.

Liam places a mirror on the ground 20 feet from a building and stands 4 feet behind the mirror. His eye is 6 feet above the ground and he sees the top of the building in the mirror. Find the height of the building.

Exercise 18 – A-frame ladder

An A-frame ladder has legs 10 feet long. A crossbar parallel to the floor is attached 4 feet from the top along each leg. The legs are 5 feet apart at the floor. Find the length of the crossbar.

Exercise 19 – Sail altitude

Sail with legs 15 and 20.

A right triangular sail has legs 15 feet and 20 feet. Find the length of the altitude from the right angle to the long edge.

Exercise 20 – Land parcels

Two triangular parcels are similar with scale factor 3 : 5. The smaller parcel has an area of 54 square yards. Find the area of the larger parcel.

Key facts behind this similar triangles worksheet

Key facts

Triangle Proportionality: DE parallel to BC gives AD/DB = AE/EC.
Triangle similarity tests: AA, SAS~ and SSS~.
Altitude to the hypotenuse: h squared = p times q.
Leg relationship: a squared = p times c.
Similar triangles let you measure heights and widths indirectly.

How to use this similar triangles worksheet

Work through the exercises in order: they go from simple to challenging. Write every step on paper, then compare with the solutions page and redo any exercise you missed the next day.
