Least-Squares Regression Line
In short: Least-squares regression line is the straight line that predicts y from x by making the sum of the squared vertical distances from the data points to the line as small as possible.
AP StatisticsStatisticsAP Statistics Unit 5
What is Least-Squares Regression Line?
The least-squares regression line is the best-fitting straight line through a scatterplot, in a specific sense: no other line has a smaller sum of squared residuals. A residual is the vertical gap between an observed point and the line.
It is written \(\hat{y} = a + bx\). The slope is \(b = r\,\frac{s_y}{s_x}\), the intercept is \(a = \bar{y} – b\bar{x}\), and the line always passes through the point \((\bar{x}, \bar{y})\). The slope says how much the predicted \(y\) changes for each one-unit increase in \(x\); the intercept is the prediction at \(x = 0\), which may not be meaningful.
How to spot it
- A scatterplot with a linear trend is given and a prediction for a new x is requested from the least-squares regression line.
- Summary statistics, means, standard deviations and r, are provided and the equation of a line is wanted.
- A question asks to interpret the slope or intercept in context.
- Computer output lists “Constant” and a coefficient for the explanatory variable.
The method
- Compute the slope \(b = r\,\frac{s_y}{s_x}\), or \(b = \frac{\sum (x – \bar{x})(y – \bar{y})}{\sum (x – \bar{x})^2}\).
- Find the intercept \(a = \bar{y} – b\bar{x}\).
- Write the least-squares regression line \(\hat{y} = a + bx\), and use it to predict, staying within the range of the observed \(x\) values.
- Check residuals: \(y – \hat{y}\) should add to zero and show no curved pattern.
Least-Squares Regression Line: solved example
Problem
Five students record hours studied \(x\) and quiz score \(y\): (1, 55), (2, 62), (3, 70), (4, 74), (5, 84). Find the least-squares line, predict the score for 3.5 hours, and find the residual at \(x = 4\).
Solution
\(\bar{x} = 3\) and \(\bar{y} = 69\). Then \(\sum (x – 3)(y – 69) = 28 + 7 + 0 + 5 + 30 = 70\) and \(\sum (x – 3)^2 = 10\), so \(b = 7\). Intercept: \(a = 69 – 7(3) = 48\).
The line is \(\hat{y} = 48 + 7x\). At 3.5 hours: \(48 + 24.5 = 72.5\).
At \(x = 4\) the prediction is 76 and the actual score is 74, so the residual is \(74 – 76 = -2\).
Try it
Question 1
Interpret the slope 7 in the quiz example.
Show the answer
For each additional hour studied, the predicted quiz score increases by about 7 points.
Question 2
A line has \(r = 0.8\), \(s_x = 5\), \(s_y = 15\), \(\bar{x} = 20\), \(\bar{y} = 100\). Find the equation.
Show the answer
\(b = 0.8 \times \frac{15}{5} = 2.4\) and \(a = 100 – 2.4(20) = 52\), so \(\hat{y} = 52 + 2.4x\).
Least-Squares Regression Line vs. Residual
The least-squares regression line is the model, one formula for all predictions. A residual is the leftover for one particular observation: actual value minus predicted value. The line is chosen so that the residuals are as small as possible overall, in the sense of squared size.
